ATV TL-A02

Terrain vehicle ATV TL-A02

This product was designed in 2014

Retro Willys Mini for all kinds of teen driving

Steel tube frame, front and rear shock absorption

With power steering and hydraulic braking system, the whole vehicle adopts ABS plastic shell

Equipped with headlights, turn signals, horns, rear tail lights (brake lights, reversing lights)

Adopt 50cc/70cc/90cc/110cc engine, reverse gear + N gear + forward 1/2/3 gear switching.

Equipped with windshield, leather seats, seat belts, mirrors, parking brake

Can be installed: trailer ball head, electric winch, etc.

Inquiry Now

Descriptions

Terrain vehicle ATV TL-A02

Engine Model: 50cc/70cc/90cc/110cc, 4 units

Maximum torque: 4.2Nm/5000rpm, 4.2Nm/5000rpm, 5.2Nm/5000rpm, 5.5Nm/5000rpm

Maximum power: 3.0Kw/8500rpm/, 3.0kw/7500rpm, 3.3kw/7500rpm, 3.6kw/7500rpm,

Ignition Type: CDI

Transmission: Automatic, Chained

Brakes (Front/Rear): Drum/Disc

Starting System: Electric Start

Battery Specifications: 12V, 4AH

Front Suspension Details: Double A x swingarm

Rear Suspension Details: Single Swing Shock Swing Arm

Front Wheel Size: 145/70-6 Rear Wheel Size: 145/70-6

Vehicle size: 152x86x91cm

Wheelbase: 880mm

Height from the ground: 60cm

Ground clearance: 100mm

Load capacity: 75kg

Fuel tank capacity: 3.2L

Carton gross weight: 90.5kg

Net weight: 83kg

Package size: 125x76x66cm
